♦ High accuracy
♦ Calibrated to national standards
♦ Aluminum alloy construction
♦ Compact Design
♦ Easy to install
♦ Long term, reliable operation

♦ Usage & Applications：
- price computing scales
- counting scales
- weighing scales
- retail scales

♦ Capacity: 20kg
♦ Rated Output: 2.0 mV/V±10%
♦ Zero Balance: ±0.0200 mV/V
♦ Non-linearity: 0.02 %R.O.
♦ Hysteresis: 0.02 %R.O.
♦ Repeatability: 0.02 %R.O.
♦ 30mins Creep: 0.02 %R.O.
♦ 30mins Return: 0.02 %R.O.
♦ Safe Overload: 150 %R.O.
♦ Ultimate Overload: 200 %R.O.
♦ Temperature Effect On Output: 0.002 %R.O./℃
♦ Temperature Effect On Zero: 0.003 %R.O./℃
♦ Input Impedance: 410±15 Ω；1130±30 Ω
♦ Output Impedance: 350±5 Ω； 1000±10 Ω
♦ Insulation Impedance: ≥5000 MΩ/(50VDC)
♦ Recommended Excitation:5~12 VDC
♦ Maximum Excitation: 15 VDC
♦ Operating Temperature Range: -20~60 ℃
♦ Construction: Aluminum Alloy
♦ Protection Class: IP66 / IP67
♦ Cable: φ4×0.5m
♦ Mode of Connection
- Red（EXC+）
- Black（EXC-)
- Green（SIG+）
- White（SIG-）
